Delock 11827 Power Monitoring Smart Plug

General Notes

Model reference: 11827

Manufacturer: Delock

The device comes pre-flashed with Tasmota. Flashing ESPHome is easily possible by uploading an ESPHome .bin file using the device's web interface.

GPIO Pinout

Pin	Function
GPIO3	Button (inverted)
GPIO4	HLW8012 - CF
GPIO5	HLW8012 - CF1
GPIO12	HLW8012 - SEL
GPIO13	LED
GPIO14	Relay

HLW8012 Calibration Values

Value
Current	0.0009356
Voltage	2182

Values vary between devices, should be calibrated.

Basic Config

Basic configuration with switch and power/voltage/current reporting.

substitutions:
  plug_name: delock01
  # Higher value gives lower watt readout. Calibrate for higher accuracy.
  current_res: "0.0009356"
  # Lower value gives lower voltage readout. Calibrate for higher accuracy.
  voltage_div: "2182"

esphome:
  name: ${plug_name}

esp8266:
  board: esp8285

wifi:
  ssid: !secret wifi_ssid
  password: !secret wifi_password
  # Enable fallback hotspot (captive portal) in case wifi connection fails
  ap:
    ssid: "${plug_name} Fallback Hotspot"
    password: "7xlV0YQ3J35a"

captive_portal:

# Enable logging
logger:

# Enable Home Assistant API
api:
  encryption:
    key: !secret api_encryption_key

ota:
  password: !secret esphome_ota_pw

# Example configuration entry
web_server:
  port: 80

# Example configuration entry
sensor:
  - platform: hlw8012
    sel_pin:
      number: GPIO12
      inverted: true
    cf_pin: GPIO04
    cf1_pin: GPIO05
    current:
      name: "${plug_name} Current"
      unit_of_measurement: A
      accuracy_decimals: 3
    voltage:
      name: "${plug_name} Voltage"
      unit_of_measurement: V
      accuracy_decimals: 1
    power:
      name: "${plug_name} Power"
      unit_of_measurement: W
      accuracy_decimals: 0
    voltage_divider: ${voltage_div}
    current_resistor: ${current_res}
    change_mode_every: 3
    update_interval: 3s

binary_sensor:
  - platform: gpio
    pin:
      number: GPIO3
      inverted: True
    name: "${plug_name} Button"
    on_press:
      - switch.toggle: relay

switch:
  - platform: gpio
    id: led
    pin: GPIO13

  - platform: gpio
    name: "${plug_name} Smart Plug"
    pin: GPIO14
    id: relay
    on_turn_on:
      - switch.turn_on: led
    on_turn_off:
      - switch.turn_off: led
